1P 10AX rocker switch canvas - 30020.C

Pdf
Vimar - 30020.C - 1P 10AX rocker switch canvas
Vimar - 30020.C - 1P 10AX rocker switch canvas

30020.C
Wiring devices / Traditional wiring devices / LINEA / Devices

1P 10AX rocker switch canvas
1P 10 AX 250 V~ lightable 1-way switch, canvas. Max 100 W for lamps with built-in power supply unit (IEC 60669-1:2017)

产品状态
3 - Active

您可能也感兴趣

30024.C
30024.C - 1P 10AX 2-way rocker switch canvas
30032.LC
30032.LC - 1P 10AX rocker revers.switch +LED canvas
30008.C
30008.C - 1P NO 10A button canvas
00936.250.W
00936.250.W - LED unit 250V 0,35W white

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Untreated
Surface finishing
Matt
Colour
Beige
RAL-number (similar)
7032
Label space/information surface
No
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Impact strength
Other
Nominal voltage
250 V
Rated current
10,00 A
Switching current for fluorescent lamps
10
Feedback-signal contact
No
Connection type
Screwed terminal
Heating switch
No
Washing machine switch
No
Device width
22,30 mm
Device height
52,80 mm
Device depth
31,90 mm
Built-in depth
23,50 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No

00. CE Marking - EU

01. IMQ - Italy

13. SNI-MGI - Indonesia

37. Marking - Morocco

50. Product Environm. Profile

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352687271
1 NR
3.6x2.7x5.6 [cm]
25.48 [g]
Barcode Qty 50 NR
8007352687288
50 NR
20x14.8x12.8 [cm]
1,395 [g]
Barcode Qty 300 NR
8007352687295
300 NR
47x22x27.5 [cm]
8,770 [g]
