1P 10AX 1-way switch mechanism - 30000

Pdf

Vimar - 30000 - 1P 10AX 1-way switch mechanism

30000
Wiring devices / Traditional wiring devices / LINEA / Devices

1P 10AX 1-way switch mechanism
1P 10 AX 250 V~ lightable 1-way switch mechanism, to be completed with 1-module button. Max 100 W for lamps with built-in power supply unit (IEC 60669-1:2017)

产品状态
3 - Active

您可能也感兴趣

31000S.B - White lower 1M path light button

31000S.G - Black lower 1M path light button

31000S.C - Lower 1M path light button Canvas

31000A.B - Axial button 1M white

31000A.G - Axial button 1M black

31000A.C - Axial button 1M canvas

31000.B - Button 1M aligned white

31000.G - Button 1M aligned 1M black

31000.C - Button 1M aligned Canvas

00943.W - Linea 110-250V white LED unit

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Off switch 1-pole

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Anti-bacterial treatment
No

Surface protection
Untreated

Surface finishing
Matt

Colour
Black

RAL-number (similar)
7021

Label space/information surface
No

Illumination
Optional

Function lighting
Control and orientation

Type of lighting
LED exchangeable

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
10,00 A

Switching current for fluorescent lamps
10

Feedback-signal contact
No

Connection type
Screwed terminal

Heating switch
No

Washing machine switch
No

Device width
22,30 mm

Device height
49,50 mm

Device depth
28,90 mm

Built-in depth
31,80 mm

Compatible with Apple HomeKit
No

Compatible with Google Assistant
No

Compatible with Amazon Alexa
No

IFTTT support available
No

00. CE Marking - EU

01. IMQ - Italy

13. SNI-MGI - Indonesia

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 50 NR

条形码

8007352674882

1 NR

4.6x2.7x5.6 [cm]

27.08 [g]

8007352674899

50 NR

23.7x14.8x12.8 [cm]

1,495 [g]

8007352674905

300 NR

45.5x27x27 [cm]

9,400 [g]
