22386
Wiring devices / Traditional wiring devices / EIKON / Devices
Vintage/Flat indicator unit
产品状态
3 - Active
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Information light signal for domestic switching devices
Information light signal for domestic switching devices
Assembly arrangement
Modular device for domestic switching devices
Modular device for domestic switching devices
Number of modules (module system)
1
1
Lamp holder
Other
Other
With light source
No
No
Lamp type
LED exchangeable
LED exchangeable
With flashlight
No
No
With fixed symbol/imprint
No
No
With exchangeable symbol
No
No
Application as button
No
No
Mounting method
Flush-mounted
Flush-mounted
Type of fastening
Engage (snap)
Engage (snap)
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Surface finishing
Glossy
Glossy
Colour
Grey
Grey
RAL-number (similar)
7024
7024
Transparent
No
No
Suitable for degree of protection (IP)
IP40
IP40
Nominal voltage
250 V
250 V
Device width
22,3 mm
22,3 mm
Device height
49,0 mm
49,0 mm
Device depth
26,7 mm
26,7 mm
最小订单数量: 1 NR
条形码
8007352734487
1 NR
4.1x2.8x5.3 [cm]
18.1 [g]
8007352734494
10 NR
14.4x9x6 [cm]
216.4 [g]
8007352734500
160 NR
37.5x30x13.5 [cm]
3,770 [g]
