1P 10AX 2-way switch Vintage bronze - 22004.12

Pdf

Vimar - 22004.12 - 1P 10AX 2-way switch Vintage bronze

22004.12
Wiring devices / Traditional wiring devices / EIKON / Devices

1P 10AX 2-way switch Vintage bronze
1P 10AX 2-way switch Vintage bronze. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Two-way switch

Method of operation
Other

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Other

Surface protection
Lacquered

Surface finishing
Glossy

Colour
Bronze

RAL-number (similar)
7008

Label space/information surface
Yes

Illumination
No

Function lighting
Control and orientation

Type of lighting
Other

Nominal voltage
250 V

Rated current
10,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
No

Device height
48,80 mm

00. CE Marking - EU

01. IMQ - Italy

09. VDE - Germany

13. SNI - Indonesia

15. CCC - China

19. NOM - Mexico

20. IQC - Argentina

36. ISI - India

37. Marking - Morocco

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 10 NR

条形码

8007352620766

1 NR

5.1x6.5x2.7 [cm]

33.3 [g]

8007352620773

10 NR

14.5x11x7.4 [cm]

380.5 [g]
