Frame 1M for panel mounting

Pdf

21626
Wiring devices / Traditional wiring devices / EIKON / Mounting frames

Frame 1M for panel mounting

产品状态
3 - Active

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush-mounted

Mounting method
Mounting with screw

With nail
No

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
1

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
Yes

Suitable for mounting in round junction box 60 mm
No

Flush-mounted installation
Yes

Suitable for subfloor installation duct box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

00. CE Marking - EU

01. IMQ - Italy

最小订单数量: 10 NR

8007352729056

1 NR

3.4x7.9x1 [cm]

10 [g]

8007352729063

10 NR

13.9x11.9x7.4 [cm]

140 [g]

8007352729070

200 NR

38.5x29.5x25 [cm]

3,212 [g]

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
