Round plate 2Mpan.Bright arctic white - 20697.B01

Pdf
Vimar - 20697.B01 - Round plate 2Mpan.Bright arctic white
Vimar - 20697.B01 - Round plate 2Mpan.Bright arctic white

20697.B01
Wiring devices / Traditional wiring devices / EIKON / Cover plates

Round plate 2Mpan.Bright arctic white
2-module Round cover plate for panel mounting, Bright varnished metal and white frame, arctic white

产品状态
2 - Will be discontinued

您可能也感兴趣

20627
20627 - Frame 2M for panel mounting

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
2
Mounting direction
Horizontal and vertical
Number of units horizontal
1
Number of units vertical
2
Number of modules horizontal (module system)
1
Number of modules vertical (module system)
2
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Metal
Material quality
Other
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9016
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
40,10 mm
Height
136,90 mm
Depth
8,80 mm
Built-in width
40,10 mm
Built-in height
136,90 mm
Diameter bore hole (opening)
0 mm

01. IMQ - Italy

29. QCERT - Colombia

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352317642
1 NR
14.5x4.6x2.2 [cm]
49.47 [g]
Barcode Qty 5 NR
8007352317659
5 NR
15.8x10x5.1 [cm]
286 [g]
