Classic plate 5MBS Glass silver mirror - 20649.C81

Pdf
Vimar - 20649.C81 - Classic plate 5MBS Glass silver mirror
Vimar - 20649.C81 - Classic plate 5MBS Glass silver mirror

20649.C81
Wiring devices / Traditional wiring devices / EIKON / Cover plates

Classic plate 5MBS Glass silver mirror
5-module Classic cover plate for British standard, Glass crystal and chromed frame, silver mirror

产品状态
2 - Will be discontinued

您可能也感兴趣

20609
20609 - Frame 5M BS

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
5
Mounting direction
Horizontal and vertical
Number of units horizontal
5
Number of units vertical
1
Number of modules horizontal (module system)
5
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Glass
Material quality
Glass
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9023
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
154,80 mm
Height
94,80 mm
Depth
9,70 mm
Built-in width
154,80 mm
Built-in height
94,80 mm
Diameter bore hole (opening)
0 mm

08. ASTA - UK

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352478633
1 NR
18.5x11.4x3.3 [cm]
157.4 [g]
