Vimar - 20529.120 - Two rocker push buttons+SLAVE actuator

20529.120
Smart systems&products / By-me Plus / EIKON / Devices

Two rocker push buttons+SLAVE actuator
Two rocker push buttons and actuator for SLAVE dimmer 120 V~ 60 Hz for: LED lamps and electronic transformers, RGB lamps and electronic transformers, to complete with interchangeable 1- or 2-module buttons - 2 modules

产品状态
2 - Will be discontinued

单, 说明书, 文档

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Other

Method of operation
Push button

Number of rockers
2

Number of modules (module system)
200

Number of poles
1

Nominal voltage
120 V

With lighting
Yes

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7024

Transparent
No

Label space/information surface
Yes

Imprint
None

Suitable for degree of protection (IP)
IP40

Device width
44,80 mm

Device height
49,00 mm

Device depth
36,10 mm

00. CE Marking - EU

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352487833

1 NR

11.2x9.6x9.8 [cm]

114.2 [g]
