Badge switch 230V Next - 20466.N

Pdf
Vimar - 20466.N - Badge switch 230V Next
Vimar - 20466.N - Badge switch 230V Next

20466.N
Wiring devices / Traditional wiring devices / EIKON / Devices

Badge switch 230V Next
Badge electronic switch with vertical pocket, 16 A 230 V~ relay output, supply voltage 230 V~ 50-60 Hz, with built-in 3-module mounting frame for British standard installation, Next. Supplied without ISO card (badge)

产品状态
3 - Active

单, 说明书, 文档

图纸

PNG DXF
PNG DXF
Class group
Alarm installations, emergency call and signalling
Class
Access control system
Standalone
Yes
Networkable
No
PC-binding
No
Type of interface
None
Reading strategy
Data medium
Signalling
None
Mounting method
Flush-mounted
Operating voltage AC 50 Hz
230,00 - 230,01 V
Operating voltage AC 60 Hz
230,00 - 230,01 V
Operating temperature
5 - 45 °C
Degree of protection (IP)
IP20
Colour
Silver
Material
Plastic
Width
82,50 mm
Height
82,50 mm
Depth
48,70 mm

00. CE Marking - EU

31. TISI - Thailand

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352403338
1 NR
11.7x10.8x7.1 [cm]
154.4 [g]
