20384
Wiring devices / Traditional wiring devices / EIKON / Devices
LED-emergency lamp 3M 120-230V grey
Lamp with high-efficiency LED, supply voltage 120-230 V~ 50-60 Hz, automatic emergency device, 3 rechargeable AAA 1,2 V batteries, 1 hour of operating time, grey - 3 modules
- The battery is charged continuously when powered
- Battery charging time of 15 h, operating time after charging approximately 1 h
- Supply voltage: 120-230 V~ ±10%, 50-60 Hz. Luminous flux: 22 lumen. Absorption: 0.5 W
- The lamp with LED provides auxiliary lighting in the event of a power failure; when the power returns, the lamp automatically switches off and the green LED is lit
产品状态
3 - Active
Class group
Luminaires
Luminaires
Class
Emergency luminaire
Emergency luminaire
Mounting method
Built-in
Built-in
Monitoring equipment
None
None
With remote switch connection
No
No
Power supply system
Peripheral (individual battery)
Peripheral (individual battery)
Battery quality
NiMH
NiMH
Lamp type
LED not exchangeable
LED not exchangeable
With light source
Yes
Yes
Housing material
Plastic
Plastic
Housing colour
Grey
Grey
Material cover
Without cover
Without cover
Voltage type
AC
AC
Nominal voltage
120,00 - 230,00 V
120,00 - 230,00 V
Degree of protection (IP)
IP40
IP40
Protection class
II
II
Max. system power
0,50 W
0,50 W
Rated luminous flux according to IEC 62722-2-1
22
22
Width
67,30 mm
67,30 mm
Height/depth
46,70 mm
46,70 mm
Built-in width
67,30 mm
67,30 mm
Built-in height/depth
36,50 mm
36,50 mm
最小订单数量: 1 NR
条形码
8007352269699
1 NR
11.2x9.6x9.8 [cm]
166.8 [g]
