BNC socket connector soldering grey - 20361

Pdf
Vimar - 20361 - BNC socket connector soldering grey
Vimar - 20361 - BNC socket connector soldering grey

20361
Wiring devices / Traditional wiring devices / EIKON / Devices

BNC socket connector soldering grey
Bayonet type coaxial socket connector, jack BNC, for RG58, RG59/62, RX93 cables soldering, grey

产品状态
2 - Will be discontinued

Class group
Domestic switching devices
Class
Insert/cover for communication technology
Assembly arrangement
Modular device for domestic switching devices
Utilization
BNC/TNC
Support ring
No
With dust cover
No
With hinged lid
No
With imprint
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7024
Transparent
No
Number of modules (module system)
1
With strain relief
No
Luster terminal
No
Suitable for degree of protection (IP)
IP20
Device width
22,30 mm
Device height
49,00 mm
Device depth
31,20 mm

00. CE Marking - EU

99. WEEE Directive

最小订单数量: 5 NR

条形码

Barcode Qty 1 NR
8007352250055
1 NR
5.1x2.8x5.3 [cm]
16.8 [g]
Barcode Qty 5 NR
8007352250062
5 NR
14.2x6.7x5.9 [cm]
113.67 [g]
