VGA 15P socket connector Next - 20348.N

Pdf

20348.N
Wiring devices / Traditional wiring devices / EIKON / Devices

VGA 15P socket connector Next
Socket outlet with 15P VGA connector, soldering, Next - 2 modules

产品状态
2 - Will be discontinued

图纸

Class group
Domestic switching devices
Class
Insert/cover for communication technology
Assembly arrangement
Modular device for domestic switching devices
Support ring
No
With dust cover
No
With hinged lid
No
With imprint
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9022
Transparent
No
Number of modules (module system)
2
With strain relief
No
Luster terminal
No
Suitable for degree of protection (IP)
IP20
Device width
44,80 mm
Device height
49,00 mm
Device depth
20,10 mm

00. CE Marking - EU

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352491878
1 NR
5.1x2.8x5.3 [cm]
19.3 [g]
Barcode Qty 5 NR
8007352491885
5 NR
14.2x6.7x5.9 [cm]
128.1 [g]
