MASTER dimmer 230V 500W/VA 2M grey - 20165

Pdf

Vimar - 20165 - MASTER dimmer 230V 500W/VA 2M grey

20165
Wiring devices / Traditional wiring devices / EIKON / Devices

MASTER dimmer 230V 500W/VA 2M grey
Dimmer, 230 V~ for: 40-500 W at 50 Hz, 40-400 W at 60 Hz incandescent lamps, 40-500 VA at 50 Hz, 40-400 VA at 60 Hz ferromagnetic transformers, control and regulation with built-in or from peripheral NO push buttons, MASTER function for 20166 and 14166, MOSFET+TRIAC technology, visible in darkness, protection fuse, grey - 2 modules

产品状态
2 - Will be discontinued

单, 说明书, 文档

Multilanguage instructions sheet (1826 kb)

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Dimmer

Method of operation
Push button

Type of load
Inductive load

Applicable with button
Yes

Applicable with movement sensor
No

Applicable with presence indicator
No

Applicable with time switch/timer
No

Applicable with transmission button
No

Applicable with infrared button
No

Mounting method
Flush-mounted

Type of fastening
Snapper mounting

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7024

Transparent
No

Suitable for degree of protection (IP)
IP40

Nominal voltage
230,00 - 230,01 V

Frequency
50,00 - 60,00 HZ

Control voltage
230,00 - 230,01 V

Device width
44,80 mm

Device height
49,00 mm

Device depth
42,00 mm

00. CE Marking - EU

01. IMQ - Italy

31. TISI - Thailand

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 5 NR

条形码

8007352388062

1 NR

6x5.4x5.3 [cm]

79 [g]

8007352388079

5 NR

17.2x13.1x6 [cm]

452.4 [g]
