20060
Wiring devices / Traditional wiring devices / EIKON / Devices
2P 10AX 2-way switch grey
2P 10 AX 250 V~ (6 terminals) two-button switch, with directional arrows and central OFF position, grey. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)
产品状态
3 - Active
您可能也感兴趣
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Push button
Push button
Assembly arrangement
Modular device for domestic switching devices
Modular device for domestic switching devices
Model
Other
Other
Method of operation
Other
Other
Number of rockers
1
1
Number of modules (module system)
100
100
Number of poles
2
2
Nominal voltage
250 V
250 V
Rated current
10,00 A
10,00 A
With lighting
No
No
Feedback-signal contact
No
No
Mounting method
Flush-mounted
Flush-mounted
Type of fastening
Engage (snap)
Engage (snap)
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Colour
Grey
Grey
RAL-number (similar)
7024
7024
Transparent
No
No
Label space/information surface
Yes
Yes
Suitable for degree of protection (IP)
IP40
IP40
Device width
22,30 mm
22,30 mm
Device height
49,00 mm
49,00 mm
Device depth
43,50 mm
43,50 mm
00. CE Marking - EU
14. TSE - Turkey
20. IQC - Argentina
29. QCERT - Colombia
31. TISI - Thailand
37. Marking - Morocco
最小订单数量: 10 NR
条形码
8007352253209
1 NR
5.1x2.8x5.3 [cm]
43.33 [g]
8007352253216
10 NR
14.4x11.6x6 [cm]
478.13 [g]
8007352626652
120 NR
36.5x33x13.5 [cm]
5,138.4 [g]
| 问题： | If I press a push button, does it stay in position until the opposite push button is pressed? |
|---|---|
| 回答： | The product is a 2-pole switch, with a central OFF position. When one of the two push buttons is pressed, it remains in position (allowing the movement of the roller shutter/curtain) until the other push button is pressed to restore it to the neutral position. |
| 问题： | Can the product be fully opened by pressing the push button once? |
| 回答： | Yes. Upon pressure, the product even remains on after you release it, allowing the continuous closure of the circuit to which it is connected without having to hold it down. |
