Vimar - 20023 - Button 3M grey
Vimar - 20023 - Button 3M grey

20023
Wiring devices / Traditional wiring devices / EIKON / Buttons

Button 3M grey
Interchangeable 3-module button, lightable, grey

产品状态
3 - Active

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Control element/cover plate for domestic switching devices
Model
One-part rocker
Imprint/indication
None
Utilization
Switch/push button
Suitable for touch sensor connector for bus system
No
Type of fastening
Clamp mounting
Monitoring window/light outlet
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7024
With label area
No
With exchangeable lens/symbol
No
Suitable for degree of protection (IP)
IP40
Depth
1.115,00 mm

00. CE Marking - EU

01. IMQ - Italy

29. QCERT - Colombia

96. Electrotechnical expert

最小订单数量: 2 NR

条形码

Barcode Qty 1 NR
8007352252875
1 NR
6.73x4.9x2.29 [cm]
14.4 [g]
Barcode Qty 2 NR
8007352252882
2 NR
5.3x3.9x7.6 [cm]
35.33 [g]
Barcode Qty 10 NR
8007352730885
10 NR
20.6x8.5x6 [cm]
176.7 [g]
