2P 32A 1-way switch grey - 20017

Pdf

Vimar - 20017 - 2P 32A 1-way switch grey

20017
Wiring devices / Traditional wiring devices / EIKON / Devices

2P 32A 1-way switch grey
2P 32 A 250 V~ 1-way switch, lightable, with built-in frame for installation in square British standard mounting boxes, to complete with 3-module British standard cover plate, grey. Max 200 W for integrated ballast lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
2-pole switch

Method of operation
Rocker/button

Assembly arrangement
Other

Number of modules (module system)
3

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Screw mounting

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7024

Label space/information surface
Yes

Illumination
Optional

Function lighting
Control and orientation

Type of lighting
LED exchangeable

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
32,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
Yes

Device width
82,50 mm

Device height
82,50 mm

Device depth
32,50 mm

Built-in depth
22,50 mm

00. CE Marking - EU

31. TISI - Thailand

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 10 NR

条形码

8007352406582

1 NR

8.5x3.9x8.6 [cm]

114.8 [g]

8007352406599

10 NR

20.7x18.5x9.6 [cm]

1,246 [g]
