Plate8M(2+2+2+2x71)techno antibact.white

Pdf

Vimar - 19669.AB.74 - Plate8M(2+2+2+2x71)techno antibact.white

19669.AB.74
Wiring devices / Traditional wiring devices / ARKÉ / Cover plates

Plate8M(2+2+2+2x71)techno antibact.white
8-module Classic cover plate (2+2+2+2, 71 mm distance between centres), technopolymer, antibacterial material, white

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Cover frame for domestic switching devices

Number of units
8

Mounting direction
Horizontal and vertical

Number of units horizontal
8

Number of units vertical
1

Number of modules horizontal (module system)
8

Number of modules vertical (module system)
1

With mounting grid
No

Suitable for subfloor installation duct box
Yes

Suitable for wall duct
Yes

Suitable for built-in installation
Yes

Label space/information surface
Yes

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Other

Surface finishing
Matt

Colour
White

RAL-number (similar)
9016

Transparent
No

With hinged lid
No

Degree of protection (IP)
IP00

Type of fastening
Clamp mounting

Width
303,00 mm

Height
90,00 mm

Depth
8,60 mm

Built-in width
303,00 mm

Built-in height
90,00 mm

Diameter bore hole (opening)
0 mm

00. CE Marking - EU

01. IMQ - Italy

最小订单数量: 1 NR

条形码

8007352653344

1 NR

30.3x9x0.8 [cm]

47.66 [g]

8007352653351

5 NR

31.2x10.3x5.7 [cm]

318.13 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
