19485
Smart systems&products / By-me Plus / ARKÉ / Devices
IR motion detector grey
Passive infrared motion detector, grey - 2 modules
产品状态
3 - Active
单, 说明书, 文档
图纸
Class group
Installation bus systems
Installation bus systems
Class
Movement sensor for bus system
Movement sensor for bus system
Bus system KNX
No
No
Bus system KNX-RF (Radio Frequent)
No
No
Bus system radio frequent
No
No
Bus system LON
No
No
Bus system Powernet
No
No
Other bus systems
Other
Other
Radio frequent bidirectional
No
No
Model
Movement sensor
Movement sensor
Mounting method
Flush-mounted
Flush-mounted
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Colour
Grey
Grey
RAL-number (similar)
7015
7015
Transparent
No
No
With bus connection
Yes
Yes
Substation input
No
No
Creep-under protection
No
No
Operation mode switch
No
No
Animal zone
No
No
Staircase light controller
No
No
Response value luminosity adjustable
Yes
Yes
Teach-function for response value luminosity
No
No
Switch-off delay self-learning
No
No
DALI-2 certified
No
No
Optimum mounting height
1,20 m
1,20 m
Max. reach sideways
0,00 m
0,00 m
Max. reach frontally
10 m
10 m
Diameter reach on floor
0 m
0 m
Detection angle vertical
0 - 36
0 - 36
Detection angle horizontal
0,00 - 112,00
0,00 - 112,00
Number of channels
1
1
Switching power
0 W
0 W
Min. switch-on time
10 s
10 s
Max. duty cycle
250 min
250 min
Min. depth of built-in installation box
30 mm
30 mm
00. CE Marking - EU
01. IMQ - Italy
37. Marking - Morocco
最小订单数量: 1 NR
条形码
8007352451025
1 NR
11.2x9.6x9.8 [cm]
107.9 [g]
分享
合法
Vimar保留随时修改所示产品的特性的权利，恕不另行通知。 安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。 有关产品卡信息的使用条件，请参阅 使用条件。
