Pocket switch NFC/RFID AGB grey - 19468

Pdf
Vimar - 19468 - Pocket switch NFC/RFID AGB grey
Vimar - 19468 - Pocket switch NFC/RFID AGB grey

19468
Wiring devices / Traditional wiring devices / ARKÉ / Devices

Pocket switch NFC/RFID AGB grey
NFC/RFID electronic transponder card reader for installation inside the room, compatible with AGB Electronic Solutions for Hotels, vertical pocket, 1 relay output 10 A 230 V~ NO (NON SELV), 1 relay output 4 A 230 V~ NO (NON SELV), power supply 120-230 V~ 50/60 Hz, pocket backlighting for visible in darkness, grey - 3 modules. Supplied without card (badge)

产品状态
3 - Active

Class group
Alarm installations, emergency call and signalling
Class
Access control system
Standalone
Yes
Networkable
No
PC-binding
No
Type of interface
None
Reading strategy
Data medium
Signalling
Buzzer
Mounting method
Flush-mounted
Operating voltage AC 50 Hz
120,00 - 230,00 V
Operating voltage AC 60 Hz
120,00 - 230,00 V
Operating temperature
0 - 40 °C
Degree of protection (IP)
IP20
Colour
Grey
Material
Plastic
Width
67,30 mm
Height
49,00 mm
Depth
50,30 mm

00. CE Marking - EU

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352573390
1 NR
5.2x5.7x7.6 [cm]
96.9 [g]
Barcode Qty 5 NR
8007352573406
5 NR
21.4x11.6x6 [cm]
543.9 [g]
