Axial 1P 10AX 1-way switch grey - 19100

Pdf
Vimar - 19100 - Axial 1P 10AX 1-way switch grey
Vimar - 19100 - Axial 1P 10AX 1-way switch grey

19100
Wiring devices / Traditional wiring devices / ARKÉ / Devices

Axial 1P 10AX 1-way switch grey
Axial 1P 10 AX 250 V~ 1-way switch, lightable, replaceable button, grey. Max 100 W for lamps with built-in power unit(IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
10,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No

00. CE Marking - EU

01. IMQ - Italy

15. CCC - China

28. NSW - Australia

29. QCERT - Colombia

36. ISI - India

37. Marking - Morocco

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352684942
1 NR
5.1x2.8x5.3 [cm]
28.6 [g]
Barcode Qty 20 NR
8007352684959
20 NR
27x11.6x6 [cm]
637.4 [g]
Barcode Qty 120 NR
8007352684966
120 NR
37.5x30x13.5 [cm]
4,184.4 [g]
