Vimar - 19083.M - 2P 16(3)A 1-way switch +key Metal

19083.M
Wiring devices / Traditional wiring devices / ARKÉ / Devices

2P 16(3)A 1-way switch +key Metal
Independent mounting 2P 16(3) A 250 V~ key-operated 1-way switch, with key removable in both positions, metal. To be installed with the appropriate accessories from the Arké series. Protection degree: IP20, Degree of pollution: II, Overvoltage category: III, for conductors from 1.5 mm2 to 4 mm2, complete circuit disconnection, Tracking index: PTI250, Glow wire 850°C

产品状态
3 - Active

视频

Arké lives in your time

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
2-pole switch

Method of operation
Key

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
0

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Lacquered

Surface finishing
Matt

Colour
Aluminium

RAL-number (similar)
9007

Label space/information surface
Yes

Illumination
No

Function lighting
Other

Type of lighting
Other

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
16,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
Yes

Device width
22,20 mm

Device height
49,00 mm

Device depth
43,50 mm

Built-in depth
33,00 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

29. QCERT - Colombia

31. TISI - Thailand

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

8007352600751

1 NR

5.1x2.8x5.3 [cm]

55.4 [g]

8007352601079

20 NR

27x11.6x6 [cm]

1,174 [g]
