Antibacterial 1P 16AX reversing switch g - 19013.AB

Pdf
Vimar - 19013.AB - Antibacterial 1P 16AX reversing switch g
Vimar - 19013.AB - Antibacterial 1P 16AX reversing switch g

19013.AB
Wiring devices / Traditional wiring devices / ARKÉ / Devices

Antibacterial 1P 16AX reversing switch g
1P 16 AX 250 V~ reversing switch, lightable, replaceable button, antibacterial material, grey. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Intermediate switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Other
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device width
22,30 mm
Device height
49,00 mm
Device depth
36,85 mm
Built-in depth
25,00 mm

00. CE Marking - EU

99. WEEE Directive

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352651906
1 NR
4.1x2.8x5.3 [cm]
36.54 [g]
Barcode Qty 50 NR
8007352651913
50 NR
21.6x11.6x14.3 [cm]
1,775 [g]
Barcode Qty 500 NR
8007352653689
500 NR
57.5x22.5x30 [cm]
18,270 [g]
