1P NC 10A push button mechanism - 19010.0

Pdf

Vimar - 19010.0 - 1P NC 10A push button mechanism

19010.0
Wiring devices / Traditional wiring devices / ARKÉ / Devices

1P NC 10A push button mechanism
1P NC 10 A 250 V~ push button mechanism, lightable, to complete with 1, 2 or 3-module button

产品状态
3 - Active

视频

Arké lives in your time

图纸

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Single push button

Method of operation
Push button

Number of rockers
1

Number of modules (module system)
100

Number of poles
1

Nominal voltage
250 V

Rated current
10,00 A

With lighting
Yes

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
Blue

RAL-number (similar)
7015

Transparent
No

Label space/information surface
Yes

Suitable for degree of protection (IP)
IP40

Device width
22,30 mm

Device height
49,00 mm

Device depth
36,80 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

19. NOM - Mexico

29. QCERT - Colombia

36. ISI - India

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 10 NR

条形码

8007352413115

1 NR

4.1x2.8x5.3 [cm]

22.7 [g]

8007352413122

10 NR

14.4x9x6 [cm]

265 [g]
