Vimar - 19009.FX.0 - 1P 10AX reversing switch mech.screwless

19009.FX.0
Wiring devices / Traditional wiring devices / ARKÉ / Devices

1P 10AX reversing switch mech.screwless
1P 10 AX 250 V~ reversing switch mechanism, screwless terminals, lighTable, to complete with 1, 2 or 3-module button. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Intermediate switch

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
Blue

RAL-number (similar)
7015

Label space/information surface
Yes

Illumination
Optional

Function lighting
Control and orientation

Type of lighting
LED exchangeable

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
10,00 A

Switching current for fluorescent lamps
10

Feedback-signal contact
No

Connection type
Push-in clamp

Washing machine switch
No

Device width
22,30 mm

Device height
49,00 mm

Device depth
38,30 mm

Built-in depth
26,90 mm

00. CE Marking - EU

04. NF - France

09. VDE - Germany

37. Marking - Morocco

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352629967

1 NR

4.1x2.8x5.3 [cm]

26.9 [g]

8007352629974

20 NR

27x11.6x6 [cm]

597.2 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
