1P 16AX 2-way switch grey - 19005

Pdf

Vimar - 19005 - 1P 16AX 2-way switch grey

19005
Wiring devices / Traditional wiring devices / ARKÉ / Devices

1P 16AX 2-way switch grey
1P 16 AX 250 V~ 2-way switch, lightable, replaceable button, grey. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

您可能也感兴趣

19005.B - 1P 16AX 2-way switch white

19005.M - 1P 16AX 2-way switch Metal

00936.250.W - LED unit 250V 0,35W white

视频

Arké lives in your time

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Two-way switch

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7015

Label space/information surface
Yes

Illumination
Optional

Function lighting
Control and orientation

Type of lighting
LED exchangeable

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
16,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
No

Device width
22,30 mm

Device height
49,00 mm

Device depth
36,80 mm

Built-in depth
25,00 mm

00. CE Marking - EU

01. IMQ - Italy

07. INGCER - Chile

13. SNI-MGI - Indonesia

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

26. SASO - Saudi Arabia

28. NSW - Australia

29. QCERT - Colombia

31. TISI - Thailand

34. PSE - Japan

36. ISI - India

37. Marking - Morocco

50. Product Environm. Profile

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 50 NR

条形码

8007352412682

1 NR

4.1x2.8x5.3 [cm]

28.7 [g]

8007352412699

50 NR

21.4x11.6x14.2 [cm]

1,520 [g]

8007352412705

500 NR

57.5x22.5x30 [cm]

15,680 [g]

8007352750470

10,500 NR

120x80x105 [cm]

329,280 [g]
