Vimar - 17086.B - Frame 1M smooth no/screws ø60/56x56mm w

17086.B
Wiring devices / Traditional wiring devices / IDEA / Mounting frames

Frame 1M smooth no/screws ø60/56x56mm w
1-module mounting frame, smooth front, without screws, for 60 mm fixing centers, 56x56 mm flush or 09971 surface mounting boxes, white

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush-mounted

Mounting method
Mounting with screw

Mounting method of the module inserts
Back side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
1

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
No

Suitable for mounting in round junction box 60 mm
No

Flush-mounted installation
Yes

Suitable for subfloor installation duct box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

00. CE Marking - EU

01. IMQ - Italy

96. Electrotechnical expert

最小订单数量: 50 NR

条形码

8007352096622

1 NR

8.5x7.5x1.5 [cm]

21.13 [g]

8007352096639

50 NR

30.5x21.2x11.4 [cm]

1,213.8 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
