Frame 1M smooth front+claws grey

Pdf

17080
Wiring devices / Traditional wiring devices / IDEA / Mounting frames

Frame 1M smooth front+claws grey
1-module mounting frame, smooth front, with claws, for ø 60 mm round flush or 09971 surface mounting boxes, grey

产品状态
3 - Active

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush-mounted

Mounting method
Mounting with claw

Mounting method of the module inserts
Back side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
1

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
No

Suitable for mounting in round junction box 60 mm
Yes

Flush-mounted installation
Yes

Suitable for subfloor installation duct box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

00. CE Marking - EU

最小订单数量: 50 NR

8007352090811

1 NR

7.5x7.5x2 [cm]

30.4 [g]

8007352090828

50 NR

35.5x24.8x8.7 [cm]

1,715.33 [g]

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
