Classica plate 1Mpan techn.black

Pdf

Vimar - 16786.16 - Classica plate 1Mpan techn.black

16786.16
Wiring devices / Traditional wiring devices / IDEA / Cover plates

Classica plate 1Mpan techn.black
1-module Classica cover plate, technopolymer, for panel mounting, black

产品状态
3 - Active

您可能也感兴趣

16771 - Frame 1M for panel mounting

图纸

PNG DXF

Class group
Domestic switching devices

Class
Cover frame for domestic switching devices

Number of units
1

Mounting direction
Horizontal and vertical

Number of units horizontal
1

Number of units vertical
1

Number of modules horizontal (module system)
1

Number of modules vertical (module system)
1

With mounting grid
Yes

Suitable for subfloor installation duct box
Yes

Suitable for wall duct
Yes

Suitable for built-in installation
Yes

Label space/information surface
Yes

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Glossy

Colour
Black

RAL-number (similar)
9005

Transparent
No

With hinged lid
No

Degree of protection (IP)
IP00

Type of fastening
Clamp mounting

Width
40,00 mm

Height
80,00 mm

Depth
9,00 mm

Built-in width
40,00 mm

Built-in height
80,00 mm

Diameter bore hole (opening)
0 mm

00. CE Marking - EU

01. IMQ - Italy

最小订单数量: 1 NR

条形码

8007352080980

1 NR

4x8x0.9 [cm]

7.13 [g]

8007352080997

10 NR

12.3x9.6x5.1 [cm]

104 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
