Classica plate 1Mpan metal ivory

Pdf

Vimar - 16781.10 - Classica plate 1Mpan metal ivory

16781.10
Wiring devices / Traditional wiring devices / IDEA / Cover plates

Classica plate 1Mpan metal ivory
1-module Classica cover plate, die-cast metal, for panel mounting, ivory

产品状态
2 - Will be discontinued

您可能也感兴趣

16771 - Frame 1M for panel mounting

图纸

PNG DXF

Class group
Domestic switching devices

Class
Cover frame for domestic switching devices

Number of units
1

Mounting direction
Horizontal and vertical

Number of units horizontal
1

Number of units vertical
1

Number of modules horizontal (module system)
1

Number of modules vertical (module system)
1

With mounting grid
Yes

Suitable for subfloor installation duct box
Yes

Suitable for wall duct
Yes

Suitable for built-in installation
Yes

Label space/information surface
Yes

Material
Metal

Material quality
Other

Halogen free
Yes

Surface protection
Lacquered

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9010

Transparent
No

With hinged lid
No

Degree of protection (IP)
IP00

Type of fastening
Clamp mounting

Width
40,00 mm

Height
80,00 mm

Depth
9,00 mm

Built-in width
40,00 mm

Built-in height
80,00 mm

Diameter bore hole (opening)
0 mm

00. CE Marking - EU

01. IMQ - Italy

最小订单数量: 1 NR

条形码

8007352082595

1 NR

8.6x4.3x1.03 [cm]

41.2 [g]

8007352083363

10 NR

12.3x9.6x5.1 [cm]

440.17 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
