16726
System infrastructure / Enclosures and control units / Switchboards / Shared accessories
Frame 1M for DIN rail
1-module frame for DIN (60715 TH35) rail installation, occupies 2 17,5 mm modules, RAL 7035 grey
产品状态
3 - Active
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Holder for modular domestic switching devices
Holder for modular domestic switching devices
Model
Flush-mounted
Flush-mounted
Mounting method
Snap mounting
Snap mounting
Mounting method of the module inserts
Back side
Back side
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of modules horizontal (module system)
1
1
Number of modules vertical (module system)
1
1
With built-in installation box
No
No
With screws
No
No
Suitable for mounting in round junction box 60 mm
No
No
Flush-mounted installation
No
No
Suitable for subfloor installation duct box
No
No
Suitable for wall duct
No
No
Suitable for mounting on DIN-rail 35 mm
Yes
Yes
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
最小订单数量: 20 NR
条形码
8007352133389
1 NR
7.6x3.5x5.9 [cm]
20.8 [g]
8007352133396
20 NR
28.4x18.4x9.5 [cm]
528.6 [g]
8007352642041
240 NR
59x38.5x30 [cm]
7,086 [g]
