1P 10AX 2-way switch grey - 16140

Pdf
Vimar - 16140 - 1P 10AX 2-way switch grey
Vimar - 16140 - 1P 10AX 2-way switch grey

16140
Wiring devices / Traditional wiring devices / IDEA / Devices

1P 10AX 2-way switch grey
1P 10 AX 250 V~ 2-way switch (3 terminals) with directional arrows and central OFF position, grey. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Rocker
Number of rockers
1
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
No
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
24,80 mm
Device height
50,10 mm
Device depth
43,60 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

15. CCC - China

20. IQC - Argentina

28. NSW - Australia

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352002494
1 NR
5.1x2.8x5.3 [cm]
33.6 [g]
Barcode Qty 10 NR
8007352264083
10 NR
14.4x11.6x6 [cm]
379.13 [g]
Barcode Qty 120 NR
8007352643284
120 NR
36.5x33x13.5 [cm]
5,328 [g]
