Two 1P NO 10A pushes grey - 16121

Pdf
Vimar - 16121 - Two 1P NO 10A pushes grey
Vimar - 16121 - Two 1P NO 10A pushes grey

16121
Wiring devices / Traditional wiring devices / IDEA / Devices

Two 1P NO 10A pushes grey
Two independent push buttons, 1P NO + 1P NO 10 A 250 V~. They allow the simultaneous closing of the two circuits and are thus not suitable for reversing motors (rollers, gates, etc.)

产品状态
3 - Active

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Number of rockers
2
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
No
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
24,80 mm
Device height
50,10 mm
Device depth
38,00 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

20. IQC - Argentina

28. NSW - Australia

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352003750
1 NR
4.1x2.8x5.3 [cm]
33.13 [g]
Barcode Qty 20 NR
8007352000650
20 NR
21.4x11.6x6 [cm]
720.67 [g]
Barcode Qty 200 NR
8007352637313
200 NR
30.5x25.5x22.5 [cm]
7,506 [g]
