1P 16AX 2-way switch luminous grey

Pdf

Vimar - 16025 - 1P 16AX 2-way switch luminous grey

16025
Wiring devices / Traditional wiring devices / IDEA / Devices

1P 16AX 2-way switch luminous grey
1P 16 AX 250 V~ 2-way switch, luminous, for signalling unit, grey. Provided without signalling unit. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Two-way switch

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7015

Label space/information surface
Yes

Illumination
Optional

Function lighting
Control and orientation

Type of lighting
LED exchangeable

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
16,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
No

Device width
24,80 mm

Device height
50,10 mm

Device depth
36,50 mm

Built-in depth
23,30 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

20. IQC - Argentina

28. NSW - Australia

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

8007352078246

1 NR

4.1x2.8x5.3 [cm]

30 [g]

8007352078253

20 NR

21.4x11.6x6 [cm]

657.33 [g]

8007352641136

200 NR

30.5x25.5x22.5 [cm]

7,240 [g]
