1P 16AX reversing switch grey - 16013

Pdf
Vimar - 16013 - 1P 16AX reversing switch grey
Vimar - 16013 - 1P 16AX reversing switch grey

16013
Wiring devices / Traditional wiring devices / IDEA / Devices

1P 16AX reversing switch grey
1P 16 AX 250 V~ reversing switch, grey. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Intermediate switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device width
24,80 mm
Device height
50,10 mm
Device depth
39,30 mm
Built-in depth
26,10 mm

00. CE Marking - EU

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

20. IQC - Argentina

28. NSW - Australia

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352002821
1 NR
4.1x2.8x5.3 [cm]
35.4 [g]
Barcode Qty 50 NR
8007352000063
50 NR
21.4x11.6x14.2 [cm]
1,855.8 [g]
Barcode Qty 500 NR
8007352636361
500 NR
57.5x22.5x30 [cm]
19,920 [g]
