1P 16AX 2-way switch luminescent white

Pdf

Vimar - 16005.F.B - 1P 16AX 2-way switch luminescent white

16005.F.B
Wiring devices / Traditional wiring devices / IDEA / Devices

1P 16AX 2-way switch luminescent white
1P 16 AX 250 V~ 2-way switch, with luminescent indicator, white

产品状态
2 - Will be discontinued

图纸

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Two-way switch

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
White

RAL-number (similar)
9001

Label space/information surface
Yes

Illumination
No

Function lighting
Other

Type of lighting
Other

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
16,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
No

Device width
24,80 mm

Device height
50,10 mm

Device depth
36,50 mm

Built-in depth
23,30 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

15. CCC - China

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

8007352064942

1 NR

4.1x2.8x5.3 [cm]

29.87 [g]

8007352064997

20 NR

21.4x11.6x6 [cm]

656.8 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
