Frame 1M BS white - 14606

Pdf

14606
Wiring devices / Traditional wiring devices / PLANA / Mounting frames

Frame 1M BS white
1-module mounting frame, with screws, for British standard mounting boxes, white

  • The transparency helps the installation and the wiring of devices
  • The honeycomb structure gives structural strength
  • The slots in the corners enable fixing to the panel
  • Thanks to the central slots, the support can be fixed onto the wall level

产品状态
3 - Active

Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with screw
Mounting method of the module inserts
Front side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
1
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
Yes
Suitable for mounting in round junction box 60 mm
No
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic

00. CE Marking - EU

08. ASTA - UK

29. QCERT - Colombia

最小订单数量: 40 NR

条形码

Barcode Qty 1 NR
8007352383432
1 NR
8.25x8.25x2.15 [cm]
44.95 [g]
Barcode Qty 2 NR
8007352472013
2 NR
8.25x8.25x4.5 [cm]
89.9 [g]
Barcode Qty 40 NR
8007352383449
40 NR
29.5x24.8x8.7 [cm]
1,950 [g]
