Frame 2M wihtout screws 57mm

Pdf

Vimar - 14605 - Frame 2M wihtout screws 57mm

14605
Wiring devices / Traditional wiring devices / PLANA / Mounting frames

Frame 2M wihtout screws 57mm
2-module mounting frame, without screws, for 60 mm fixing centres mounting boxes, modular, 57 mm distance between centres, for horizontal or vertical installation

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush-mounted

Mounting method
Mounting with screw

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
2

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
No

Suitable for mounting in round junction box 60 mm
No

Flush-mounted installation
Yes

Suitable for subfloor installation duct box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

00. CE Marking - EU

01. IMQ - Italy

29. QCERT - Colombia

96. Electrotechnical expert

最小订单数量: 20 NR

条形码

8007352118997

1 NR

6.02x7.08x1.52 [cm]

11.2 [g]

8007352119000

20 NR

19x14.3x9.5 [cm]

299.2 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
