Frame 2M without screws 71mm grey

Pdf

Vimar - 14603.G - Frame 2M without screws 71mm grey

14603.G
Wiring devices / Traditional wiring devices / PLANA / Mounting frames

Frame 2M without screws 71mm grey
2-module mounting frame, without screws, for 60 mm fixing centres or 56x56 mm mounting boxes, modular, 71 mm distance between centres, for horizontal or vertical installation, grey

Thanks to the central slots, the support can be fixed onto the wall level

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush-mounted

Mounting method
Mounting with screw

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
2

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
No

Suitable for mounting in round junction box 60 mm
No

Flush-mounted installation
Yes

Suitable for subfloor installation duct box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

00. CE Marking - EU

01. IMQ - Italy

15. CCC - China

29. QCERT - Colombia

96. Electrotechnical expert

最小订单数量: 50 NR

条形码

8007352136977

1 NR

7.4x7.4x1.5 [cm]

14 [g]

8007352136984

50 NR

28.6x24.8x9.6 [cm]

860.93 [g]

8007352641327

300 NR

62x26x30 [cm]

5,780 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
