Frame 2M without screws 71mm - 14603

Pdf

14603
Wiring devices / Traditional wiring devices / PLANA / Mounting frames

Frame 2M without screws 71mm
2-module mounting frame, without screws, for 60 mm fixing centres or 56x56 mm mounting boxes, modular, 71 mm distance between centres, for horizontal or vertical installation

  • The transparency helps the installation and the wiring of devices
  • The honeycomb structure gives structural strength
  • The slots in the corners enable fixing to the panel
  • The hooking teeth encourage fixing in series for the installation of multiple modules
  • Thanks to the central slots, the support can be fixed onto the wall level

产品状态
3 - Active

您可能也感兴趣

图纸

Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with screw
Mounting method of the module inserts
Front side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
2
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
No
Suitable for mounting in round junction box 60 mm
No
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic

00. CE Marking - EU

29. QCERT - Colombia

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352108943
1 NR
7.4x7.4x1.5 [cm]
13.73 [g]
Barcode Qty 50 NR
8007352108950
50 NR
28.6x24.8x9.6 [cm]
840.53 [g]
