14602
Wiring devices / Traditional wiring devices / PLANA / Mounting frames
Frame 2M +claws 71mm
2-module mounting frame, with claws, for ø 60 mm mounting boxes, modular, 71 mm distance between centres
- The transparency helps the installation and the wiring of devices
- The honeycomb structure gives structural strength
- The slots in the corners enable fixing to the panel
- The hooking teeth encourage fixing in series for the installation of multiple modules
产品状态
3 - Active
您可能也感兴趣
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Holder for modular domestic switching devices
Holder for modular domestic switching devices
Model
Flush-mounted
Flush-mounted
Mounting method
Mounting with claw
Mounting with claw
Mounting method of the module inserts
Front side
Front side
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of modules horizontal (module system)
2
2
Number of modules vertical (module system)
1
1
With built-in installation box
No
No
With screws
No
No
Suitable for mounting in round junction box 60 mm
Yes
Yes
Flush-mounted installation
Yes
Yes
Suitable for subfloor installation duct box
No
No
Suitable for wall duct
No
No
Suitable for mounting on DIN-rail 35 mm
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
最小订单数量: 50 NR
条形码
8007352108929
1 NR
7.4x7.4x1.5 [cm]
21.4 [g]
8007352108936
50 NR
28.4x24.4x11.9 [cm]
1,234.67 [g]
8007352361423
300 NR
59.5x38.5x26.5 [cm]
8,208.02 [g]
