Vertical badge switch 2M white - 14463

Pdf

Vimar - 14463 - Vertical badge switch 2M white

14463
Wiring devices / Traditional wiring devices / PLANA / Devices

Vertical badge switch 2M white
Upright electronic badge switch, 4 A 250 V~ NO (NON SELV) change-over relay output, power supply 120-230 V~ 50-60 Hz, slot lighting for location in the dark, trimmer for regulating switch-off time after removing the card, white - 2 modules. Supplied without ISO card (badge)

产品状态
3 - Active

单, 说明书, 文档

Multilanguage instructions sheet (1182 kb)

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Alarm installations, emergency call and signalling

Class
Access control system

Standalone
Yes

Networkable
No

PC-binding
No

Type of interface
None

Reading strategy
Data medium

Signalling
None

Mounting method
Flush-mounted

Operating voltage AC 50 Hz
250,00 - 250,01 V

Operating voltage AC 60 Hz
250,00 - 250,01 V

Operating temperature
5 - 35 °C

Degree of protection (IP)
IP20

Colour
White

Material
Plastic

Width
44,80 mm

Height
49,00 mm

Depth
43,50 mm

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352561373

1 NR

5.2x5.7x7.6 [cm]

70.1 [g]

8007352563759

5 NR

21.4x11.6x6 [cm]

407.1 [g]

8007352726079

50 NR

30.5x25.5x22.5 [cm]

4,071 [g]
