Vimar - 14347 - S-Video socket connector white

14347
Wiring devices / Traditional wiring devices / PLANA / Devices

S-Video socket connector white
Socket outlet with S-Video connector, 4-pin, white

产品状态
2 - Will be discontinued

图纸

PNG DXF

Class group
Domestic switching devices

Class
Insert/cover for communication technology

Assembly arrangement
Modular device for domestic switching devices

Utilization
S-Video

Support ring
No

With dust cover
No

With hinged lid
No

With imprint
No

Mounting method
Flush-mounted

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9003

Transparent
No

Number of modules (module system)
1

With strain relief
No

Luster terminal
No

Suitable for degree of protection (IP)
IP20

Device width
22,30 mm

Device height
49,00 mm

Device depth
37,60 mm

00. CE Marking - EU

99. WEEE Directive

最小订单数量: 10 NR

条形码

8007352461871

1 NR

4.1x2.8x5.3 [cm]

22 [g]

8007352461888

10 NR

14.4x9x6 [cm]

256.4 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
