MASTER dimmer 230V 500W/VA 2M white - 14165

Pdf

Vimar - 14165 - MASTER dimmer 230V 500W/VA 2M white

14165
Wiring devices / Traditional wiring devices / PLANA / Devices

MASTER dimmer 230V 500W/VA 2M white
Dimmer, supply voltage 230 V~ for: 40-500 W to 50 Hz or 40-400 W to 60 Hz incandescent lamps, 40-500 VA to 50 Hz or 40-400 VA to 60 Hz ferromagnetic transformers, control and regulation with built-in or from peripheral NO push buttons, MASTER function for 14166 and 20166, MOSFET technology, visible in darkness, fuse protection, white - 2 modules

产品状态
2 - Will be discontinued

单, 说明书, 文档

Multilanguage instructions sheet (1826 kb)

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Dimmer

Method of operation
Push button

Type of load
Inductive load

Applicable with button
Yes

Applicable with movement sensor
No

Applicable with presence indicator
No

Applicable with time switch/timer
No

Applicable with transmission button
No

Applicable with infrared button
No

Mounting method
Flush-mounted

Type of fastening
Snapper mounting

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9003

Transparent
No

Suitable for degree of protection (IP)
IP40

Nominal voltage
230,00 - 230,01 V

Frequency
50,00 - 60,00 HZ

Control voltage
230,00 - 230,01 V

Device width
44,80 mm

Device height
49,00 mm

Device depth
43,00 mm

00. CE Marking - EU

01. IMQ - Italy

31. TISI - Thailand

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 5 NR

条形码

8007352387669

1 NR

6x5.4x5.3 [cm]

79.4 [g]

8007352387676

5 NR

17.2x13.1x6 [cm]

453.9 [g]
