2P 16(3)A 1-way switch +key white - 14083

Pdf

Vimar - 14083 - 2P 16(3)A 1-way switch +key white

14083
Wiring devices / Traditional wiring devices / PLANA / Devices

2P 16(3)A 1-way switch +key white
Independent mounting 2P 16(3) A 250 V~ key-operated 1-way switch, white. To be installed with the appropriate accessories from the Plana series. Protection degree: IP20, Degree of pollution: II, Overvoltage category: III, for conductors from 1.5 mm2 to 4 mm2, complete circuit disconnection, Tracking index: PTI250, Glow wire 850°C

产品状态
3 - Active

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
2-pole switch

Method of operation
Key

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
0

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9003

Label space/information surface
Yes

Illumination
No

Function lighting
Other

Type of lighting
Other

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
16,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
Yes

Device width
22,30 mm

Device height
49,00 mm

Device depth
41,40 mm

Built-in depth
30,50 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

20. IQC - Argentina

28. NSW - Australia

29. QCERT - Colombia

31. TISI - Thailand

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

8007352108684

1 NR

5.1x2.8x5.3 [cm]

50.5 [g]

8007352108691

20 NR

27x11.6x6 [cm]

1,081.47 [g]

8007352650336

120 NR

37.5x30x13.5 [cm]

6,840 [g]
