2-button 2P 10AX 2-way switch white

Pdf

Vimar - 14060 - 2-button 2P 10AX 2-way switch white

14060
Wiring devices / Traditional wiring devices / PLANA / Devices

2-button 2P 10AX 2-way switch white
2-button 2P 10 AX 250 V~ 2-way switch (6 terminals) with directional arrows and central OFF position, white. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

您可能也感兴趣

14196 - Quid - Rolling shutters 2-way switch whi

图纸

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Other

Method of operation
Other

Number of rockers
1

Number of modules (module system)
100

Number of poles
2

Nominal voltage
250 V

Rated current
10,00 A

With lighting
No

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9003

Transparent
No

Label space/information surface
Yes

Suitable for degree of protection (IP)
IP40

Device width
22,30 mm

Device height
49,00 mm

Device depth
42,50 mm

00. CE Marking - EU

01. IMQ - Italy

07. INGCER - Chile

14. TSE - Turkey

15. CCC - China

20. IQC - Argentina

28. NSW - Australia

29. QCERT - Colombia

31. TISI - Thailand

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 10 NR

条形码

8007352108660

1 NR

5.1x2.8x5.3 [cm]

42.8 [g]

8007352263543

10 NR

14.4x11.6x6 [cm]

473.8 [g]

8007352626843

120 NR

36.5x33x13.5 [cm]

6,000 [g]

问题：	Can the product be fully opened by pressing the push button once?
回答：	Yes. Upon pressure, the product even remains on after you release it, allowing the continuous closure of the circuit to which it is connected without having to hold it down.

找不到您想要的答案吗？

问一个问题

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
