Vimar - 14018 - 2P 45A 1-way switch white

14018
Wiring devices / Traditional wiring devices / PLANA / Devices

2P 45A 1-way switch white
2P 45 A 250 V~ 1-way switch, lightable, with built-in frame for British standard square boxes, to complete with British standard cover plates, white. Max 200 W for integrated ballast lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
2-pole switch

Method of operation
Rocker/button

Assembly arrangement
Other

Number of modules (module system)
3

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Screw mounting

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9003

Label space/information surface
Yes

Illumination
Optional

Function lighting
Control and orientation

Type of lighting
LED exchangeable

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
45,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
Yes

Device width
82,50 mm

Device height
82,50 mm

Device depth
32,50 mm

Built-in depth
22,50 mm

00. CE Marking - EU

08. ASTA - UK

31. TISI - Thailand

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 10 NR

条形码

8007352406384

1 NR

8.5x3.9x8.6 [cm]

115.9 [g]

8007352406391

10 NR

20.7x18.5x9.6 [cm]

1,254 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
