1P 10AX 2-way switch white

Pdf

Vimar - 14004 - 1P 10AX 2-way switch white

14004
Wiring devices / Traditional wiring devices / PLANA / Devices

1P 10AX 2-way switch white
1P 10 AX 250 V~ 2-way switch, lightable, replaceable button, white. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

Modular series for flush mounting and surface mounting
The efficient, energy-saving LED backlighting available in several colours makes the controls visible even in the dark, while the laser-engraved or customised symbols always clearly indicate the various functions
Vimar patented Plack Clack® fixing system, which gives the lighting device added strength once the cover plate is installed
Polished and shiny dirt-proof surfaces

产品状态
3 - Active

您可能也感兴趣

00936.250.W - LED unit 250V 0,35W white

00931 - Pre-wired LED unit 110-250V 0,5W amber

00936.250.A - LED unit 250V 0,35W amber

00936.250.G - LED unit 250V 0,35W green

00936.250.R - LED unit 250V 0,35W red

00936.250.B - LED unit 250V 0,35W light blue

图纸

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Two-way switch

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9003

Label space/information surface
Yes

Illumination
Optional

Function lighting
Control and orientation

Type of lighting
LED exchangeable

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
10,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
No

Device width
22,30 mm

Device height
49,00 mm

Device depth
38,40 mm

Built-in depth
24,00 mm

00. CE Marking - EU

01. IMQ - Italy

07. INGCER - Chile

13. SNI-MGI - Indonesia

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

20. IQC - Argentina

28. NSW - Australia

29. QCERT - Colombia

31. TISI - Thailand

37. Marking - Morocco

50. Product Environm. Profile

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 50 NR

条形码

8007352106390

1 NR

4.1x2.8x5.3 [cm]

28.8 [g]

8007352106406

50 NR

21.6x11.6x14.3 [cm]

1,538 [g]

8007352263154

500 NR

57.5x22.5x30 [cm]

15,836 [g]

8007352750296

10,500 NR

120x80x105 [cm]

332,535 [g]

问题：	Are other colours available?
回答：	14004 .SL 1P 10 AX 2-way switch, back-lightable, replaceable silver button
问题：	Can the button be backlit?
回答：	It can be backlit using a dedicated pre-wired signalling unit (code 00931) or with LED signalling units in various colours and voltages.
问题：	What cable section can I secure with screw terminals?
回答：	The terminals can clamp flexible or semi-rigid cables with a section of between 0.5 mm² and 2.5 mm².
