Three 1P 20AX 1-way switches white - 14003

Pdf
Vimar - 14003 - Three 1P 20AX 1-way switches white
Vimar - 14003 - Three 1P 20AX 1-way switches white

14003
Wiring devices / Traditional wiring devices / PLANA / Devices

Three 1P 20AX 1-way switches white
Three 1P 20 AX 250 V~ 1-way switches, lightable, white - 2 modules. Max 250 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
3
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
20,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device width
44,80 mm
Device height
49,00 mm
Device depth
38,40 mm
Built-in depth
24,00 mm

00. CE Marking - EU

01. IMQ - Italy

13. SNI-MGI - Indonesia

15. CCC - China

19. NOM - Mexico

31. TISI - Thailand

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352403949
1 NR
5.1x4.3x5.3 [cm]
60.9 [g]
Barcode Qty 20 NR
8007352403956
20 NR
26.9x11.6x9 [cm]
1,309 [g]
Barcode Qty 240 NR
8007352641778
240 NR
38x28.5x35.5 [cm]
16,236 [g]
