Vimar - 14000.2 - 1P 10AX 1-way switch 2M white

14000.2
Wiring devices / Traditional wiring devices / PLANA / Devices

1P 10AX 1-way switch 2M white
1P 10 AX 250 V~ 1-way switch, lightable, replaceable button, white - 2 modules. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Off switch 1-pole

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
2

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9003

Label space/information surface
Yes

Illumination
Optional

Function lighting
Control and orientation

Type of lighting
LED exchangeable

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
10,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
No

Device width
44,80 mm

Device height
49,00 mm

Device depth
38,40 mm

Built-in depth
24,00 mm

00. CE Marking - EU

01. IMQ - Italy

13. SNI - Indonesia

14. TSE - Turkey

15. CCC - China

28. NSW - Australia

29. QCERT - Colombia

31. TISI - Thailand

37. Marking - Morocco

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

8007352119819

1 NR

5.1x4.3x5.3 [cm]

34.4 [g]

8007352119826

20 NR

26.9x11.6x9 [cm]

771 [g]

8007352636415

240 NR

38x28.5x35.5 [cm]

9,780 [g]
