09974
System infrastructure / Enclosures and control units / Connector block boxes / Surface mounting
Surface-box 3M 48mm depth white
3-module surface mounting box, 48 mm depth, for 8000 and Linea with relevants mounting frame, cover plates or self-bearing cover plates, ivory. To be installed on insulating non-perforated or metallic with earth connection surfaces.
产品状态
3 - Active
Class group
Connection material (electrotechnical)
Connection material (electrotechnical)
Class
Box/housing for surface mounting on the wall/ceiling
Box/housing for surface mounting on the wall/ceiling
Max. conductor cross section
0
0
Equipped with
None
None
Shape
Rectangular
Rectangular
Mounting method
Wall-/ceiling mounting
Wall-/ceiling mounting
Mounting in the soil
No
No
Mounting under water
No
No
For tube diameter
20/25 mm
20/25 mm
Inlet from the rear
Yes
Yes
Length
80,00 mm
80,00 mm
Width
124,00 mm
124,00 mm
Depth
48,00 mm
48,00 mm
Diameter
0 mm
0 mm
Tackable
No
No
Number of inlets
4
4
Type of housing feed-through
None
None
Material
Plastic
Plastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Colour
White
White
Degree of protection (IP)
IP20
IP20
Cover model
Other
Other
Transparent cover
No
No
Cover attachment
Screwed
Screwed
Castable
No
No
With casting compound
No
No
Sealable
No
No
Rated insulation voltage Ui
450 V
450 V
Circuit integrity
None
None
With screening
No
No
Weatherproof
No
No
Operating temperature
0 - 60 °C
0 - 60 °C
Explosion-tested version
No
No
For Ex-zone gas
None
None
For Ex-Zone dust
None
None
最小订单数量: 20 NR
条形码
8007352043862
1 NR
12x8x4 [cm]
61.73 [g]
8007352003521
20 NR
28.4x24.4x17.9 [cm]
1,458.47 [g]
